In stock English version DS-2CD2142FWD-I 4MP mini dome network cctv camera, P2P 1080p IP camera POE 120dB WDR

115.26$ 109.50$
Clear

SKU: 32658095966
Category:

Description

In stock English version DS-2CD2142FWD-I 4MP mini dome network cctv camera, P2P 1080p IP camera POE 120dB WDR

Tips: This version we offer is original English version with upgradable firmware.

Accessory:

Key Features:

Up to 4 megapixel high resolution

Full HD1080p video

Dual video streams

2.8mm/4mm/6mm fixed lens

120dB Wide Dynamic Range

3D Digital Noise Reduction

3-axis adjustment

DC12V & PoE

Support H.264+

Up to 30m IR range

IP66 weather-proof protection

IK08(-W model)/IK10(non -W model)

-S: Audio/Alarm IO

-W: Built-in Wi-Fi

Camera
Image Sensor: | 1/2.8″ Progressive Scan CMOS
Min. Illumination: | 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter time: | 1/3 s to 1/10,000 s
Lens: | 2.8mm, 4mm, 6mm @ F2.0
Lens Mount: | M12
Adjustment Range: | Pan: 0° ~ 355°, Tilt: 0° ~ 75°, Rotation: 0° ~ 355°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
H.264 code profile: | Main Profile
Video bit rate: | 32Kbps~16Mbps
Dual Stream: | Yes
Max. Image Resolution: | 2688 × 1520
Frame Rate: | 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)
Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC: | Yes, zone configurable
ROI: | Support
Network
Network Storage: | NAS (Support NFS,SMB/CIFS), ANR
Alarm Trigger: | Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception
Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Security: | One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access
System Compatibility: | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Audio: | 1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model)
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface
Alarm: | 1x alarm I/O *only for –S models
On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button: | Yes
Wi-Fi Specification (-W)
Wireless Standards: | IEEE802.11b, 802.11g, 802.11n
Frequency Range: | 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: | 20/40MHz Support
Modulation Mode: | 802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
Security: | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power: | 11b: 17±1.5dBm @ 11Mbps
11g: 14±1.5dBm @ 54Mbps
11n: 12.5±1.5dBm
Receive Sensitivity: | 11b: -90dBm @ 11Mbps (Typical)
11g: -75dBm @ 54Mpbs (Typical)
11n: -74dBm (Typical)
Transmission Rate: | 11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps
Wireless Range: | 50m(depend on environment)
General
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 10%, PoE (802.3af)
Power Consumption: | Max. 5W
Impact Protection: | IK08(-W model)/IK10(non -W model)
Weather Proof: | IP66
IR Range: | Up to 30m
Dimensions: | Φ111 × 82 (4.4” × 3.2”)
Weight: | 500g (1.1lbs)
NOTE: | “-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support
the 802.1X protocol.

Additional information

Lens (mm)

8mm,6mm,12mm,2.8mm,4mm

Type

IP Camera

Image Sensor:

1/2.8" Progressive Scan CMOS

Ships From

China

Connectivity

IP/Network Wired

Model Number

DS-2CD2142FWD-I

Video Compression Format

MJPEG,H.264

Minimum Illumination(Lux)

0.01Lux

Style

Dome Camera

Power Consumption(W)

Max. 5W

Brand Name

Hikvision

Sensor

CMOS

Supported Mobile Systems

Windows Mobile,Android,Symbian

Power Supply

With POE

Special Features

Waterproof / Weatherproof

Network Interface

RJ-45 10/100Mb Ethernet Slot

Dimensions (L x W x D)(mm)

111 * 82

Technology

Infrared

IR Distance(m)

Up to 30m

is_customized

Yes

High Definition

1080P(Full-HD)

Power Supply(V)

12 VDC, PoE (802.3af)

Supported Operating Systems

Windows 10,Windows Vista,Windows 8,Windows 7,Windows 98,Mac os,Windows XP
