Bio Door Fingerprint and RFID Card Door Access Control System & Time Attendance Kits+Magnetic lock

276.08$309.86$
Clear

SKU: 32523865540
Category:

Description

Bio Single Door Fingerprint and RFID Card Access Control System & Time Attendance Kits+Magnetic lock

Purchase, please specify colors, black, silver. Default silver

Introduction:
This product is an innovative Fingerprint Time clock as well as a professional Access Controller that can be used in both Time Attendance Check and Access Control applications, it adopts the latest and accurate industrialized algorithm. It has refined fashion, integrates Powerful attendance management software, Very competitive price with good performance, designed especially in the purpose of popularizing the fingerprint products. It could store 2,000 fingerprint templates and 30,000 transaction records. It will bring you much boon because of its excellent function and competitive price.

Features:
Suitable for the entrances and exits of apartment, multi-family houses, office, factory, hotel, school, etc.
TCP/IP Communication+ USB Flash Drive Up/Download.
Anti-dismantlement alarm, threatens alarm, unlock illegally alarm, not block alarm are available.
Dismantlement alarm, threatens alarm, unlock illegally alarm, not block alarm are available.
Arm9 CPU, big capacity FLASH and CMOS chips, Open SDK, professional technical support, easy to integrate with various systems.
Sensor with quality image, accepts dry/wet fingers. Adjust image distortion, assure fingerprint matching consistency.
Fingerprint / Card/ Password / Fingerprint + Card / Fingerprint+ Password / Card
+ Password / Fingerprint + Card+ Password identification modes are all available.

Parameters:
Model: ZD2F20
LCD Resolution: 128*64
Fingerprint Sensor Resolution: 500DPI
Rotational Angle: Total Rotational Angle
FRR: ≤0.1%
FAR: ≤0.0001%
Identification Time: ≤0.1 S
Query Record: Available
Real Time Fingerprint Picture Display: Available
Operating Mode: Off-line/On-line
Authentication Mode: 1:1, 1:N
Identification Mode: Fingerprint/ ID card/ Password
Fingerprint Capacity: 2,000
Log Capacity: 30,000 events
Communication: TCP/IP, RS485
U disk up/download: Available
Language: English, Korean
Voice prompt: Available
Capacity notification: Alarm when log capacity is full
Bell: Built-in timing bell
Lock Output: NO/ NC

Door Open Button: Can connect the common button, or the wireless remote controlled button
Doorbell Output: Can connect the doorbell in every voltages
Access Control Interface: Wiegand 26/Input/ Output Optional
Anti-pass back: Available
Alarm: Threatens Alarm, Anti-dismantlement Alarm, Unlock Illegally Alarm,
Circumscribed Alarm, Time-out Alarm
OS: Windows XP, Windows Vista, Windows 2003 (Note: the OS of Windows XP and Windows 2003 should support Microsoft, NET framework 2.0)
Operating environment: Operating Temp: 0 Celsius degree – 50 Celsius degree, Humidity:80 percent
Power: DC 12V/0.5A

Power Supply:

Power output: Standard 12VDC,3A Control electric locks or bolts directly

Lessen the load of access controller Save project wires

With UPS terminal which can connect with battery

Lower potential trouble

NC/NO output Control all kinds of electric locks

Has delay control circuit

Unlock delay time in 0~10S

Auto protective function

Dimension:215X 170 X75 MM

Magnetic Lock:

Magnetic Lock:

1,Collinear Load Test 280kg,600pounds

2,The Standard Voltage is 12VDC when Finished

3,MOV Provides Reverse Current Protection

4,Suitable For Wooden Door, Glass Door, Metal Door, 5,Fireproof Door

6,LED Indicates the Door Status

7,Lock Status sensor(NO/NC/COM)

8,Optional Bracket: ZL,L, U Bracket

9,Anti-Residual Magnetism Designed

10,High Strength Material, Anodized Aluminum Housing

11,Design without Mechanical Failure

12,Increase the holding Force, Dual Insulated Housing

RFID Tagx10:

Description:
Material: ABS
Dimension: 43.7×30.5×5.3mm
Response frequency: 125 KHz,
Chip type: EM4100, TK4100

Operation Temperature : -40°C to 85°C
Waterproof
Application scope: public transportation, parking, ID identification, attendance system, ticketing, card payment, product logo, etc.

Feature:

• Water resistant

• Each comes with Key ring included.

• Compatible with all RFID reader to gain access

• Each token pre-programmed with unique ID which is Laser printing on it

Package contents:
1* Fingerprint Access Control x 1
2* power supply x 1
3* exit botton x 1
4* rfid tag x10

5* Magnetic Lock x 1

GUARANTEE & WARRANTY:

  • 100% fully checked and QC passed from factory.
  • Original packaging and accessories produced by the manufacturer.
  • One Year Warranty from the date of shipment

Payment:

  • We accept payment by Credit Card, Bank Transfer and other Payment that Aliexpress support.
  • Payment must be received within 19 days of auction closing
  • Please list your special requests (color, packages, value of declaration, etc.) when you make payment, or send message to us.

shipping&handing

  • We Ship to Worldwide Except APO/FPO
  • We only ship to confirmed order addresses. Your order address MUST MATCH your shipping address.
  • Delivery Time:
  • SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit times may vary, particularly during the holiday season.
  • If you have not received your shipment within 30 days from we send it out, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
  • Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
  • We ship to Worldwide, and the Approx Delivery Time is referred as below:

Item

Approx. Delivery time

UPS,DHL,FEDEX,TNT

2-5 working days

EMS

5-8 working days

China Post Air Mail

US, UK, AU, Singapore,etc.

12-20 working days

Canada,New Zealand,etc.

15-22 working days

India, Germany,Israel,Spain, etc.

may take up to 4-6 weeks due to strict Custom Inspection

Russia, Brazil,Italy, France, Eastern Europe,etc.

may take up to 6-8 weeks due to strict Custom Inspection

Important duties:

  • Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyers? responsibility
  • You need to check this with your customs office to find out what these additional costs will be prior to buying
  • Before signing the package, please check to make sure the product is not damaged during the transportation and whether the product is in it. If not, please refuse to sign it. You will be considered receiving the right product as long as you signed the parcel

Refund &Return:

  • We do our best to serve our each customer the best that we can.
  • you have 14 days to return it from the date it was received. Please contact us in the 14 days. If this item is in your possession more than 14 days, it is considered used and we will not issue you a refund or replacement. hope you can understand.
  • All returned items must be in the original packaging and you must provide us with the shipping tracking number, your reason for the return, and your Aliexpress ID.
  • We will refund you upon receipt of the item in its original condition and packaging with all components and accessories included. You also can choose to have a replaceme

Feedback:

  • If you have some problem with the color, size, quality or other problem, please contact us freely before you give us a neutral/negative feedback.
  • We will leave POSITIVE FEEDBACK as soon as the Aliexpress allow us to leave feedback. We warmly like to give you satisfy solution. If you love our item, warmly expected your five stars feedback. We will work harder to give you a satisfy service.
  • Since your feedback is very important for us, we sincerely invite you to leave positive feedback for us, thank you very much!

Additional information

Brand Name

Jedrek

Model Number

F20

Function1

password door lock, biometric door lock

Function2

biometric fingerprint time clock

RFID CARD

EM4100, 125khz

Magnetic lock

600pounds

Language

English, Korean

Fingerprint Capacity

2000

Communication

TCP/IP, RS485

Identification Mode

Fingerprint/ ID card/ Password
