waterproof Mini CCTV CAMERA 8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Camera WIITH HD 2.8mm Wide-angle LENS

46.99$ 44.64$
Clear

SKU: 32672760132
Category:

Description

start

waterproof Mini CCTV CAMERA 8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Mini Camera WIITH HD 2.8MM Wide-angle LENS

SHRXY HOTsell 170 Wide Angle 800tvl CCD Wired Mini…

Price

$33.60

Amazing

$28.00

Free Shipping RXD 360 CCTV Ant home video security sur…

Price

$31.56

Amazing

$30.00

nd

8Pcs IR 940nm invisible light lamps,Better Night Vision Effective

Night Vision distance up to 5m, High-definition, grasp details in place.

Waterproof Weatherproof Anti fog

Features:

mage Sensor: 1/3″ Sony Super HAD CCD II
DSP: Effio-E (4140+811/810)
Horizontal Resolution :700TVL

Effective Pixel:NTSC:976(H) X494(V) PAL:976(H) X582(V)

Min. Illumination :0.001 Lux (F1.2)/ 0 Lux IR On
Signal System: NTSC/PAL
Lens: Standard 2.8mm
Camera Type: Indoor/Outdoor
Power Supply: DC12V/75MA

Packing list:

1 x Mini Bullet Wide-angle Camera

1 x Camera bracket with screws

1 x Retail Box

Specification Of the Camera:

Model

RX700BT

Image Sensor

1/3″ Sony Super HAD CCD II

DSP

Effio-E (4140+811/810)

Horizontal Resolution

Color Mode: 650TVL; B/W Mode:700TVL

Effective Pixel

NTSC:976(H) 494(V) PAL:976(H) 582(V)

Min. Illumination

0.001 Lux (F1.2)/ 0 Lux IR On

Signal System

NTSC/PAL

Electronic Shutter

NTSC:1/60~1/100,000, PAL:1/50~1/110,000

S/N Ratio

More than 48dB

Gamma

0.45/1.0

Exposure

Auto

OSD

Support

White Balance

ATW / User1/User2

Backlight

OFF/ON/BLC/ HLC

Pic Adjust

Mirror/Brightness/Contrast/Sharpness/Hue/Gain

ATR

ON/OFF

D-WDR

Yes

Motion Det

OFF/ON(Detect sense/ Area Sel)

Privacy Masking

OFF/ON (4 Zone)

Day/Nigh

True Day and Night (Auto/ Day / Night / Ext. D&N)

2D-NR

OFF/ON (0-15/16 level)

Camera ID

OFF/ON

Sync. System

Internal

Audio Output

Optional

Video Output

1 Vp-p / 75 Ohms

Working Conditions

-20~60Degree/0-93% Humidity

Power Supply

DC12V/75MA

Note: 3.6mm lens, PAL SYSTEM,Black housing color default for this camera. If the buyer want other size lens,other system,other color, please Leave Message to notify us when bidding.

Trouble and Solution:

1. No Picture after providing power
May be the power supply voltage abnormity, please check the power supply voltage and pole whether exactitude.
Please check all the conecting cable and monitors whether be connected correctly or not.

2. The picture level direction have flowing interference ripples
May be caused by the power supply AC ripples, it need filter the wave of the power supply.
Check the monitor and peripheral equipments used.

3. The picture background color changes continuously
The fluorescent lamp’s electromagnetic field cause color roll. This is proper phenomenon of the cameras.
Reduce the fluorescent lamp numbers or increase the distance between the camera and the fluorescent lamps can
improve it.
Use Power supply external sync. Camera can solve it.

4.The picture smear too mass
The power supply’s voltage unstable
Connecting cables not connect correctly or have high impedance.

Trouble and Solution:

PS: PAL format is for Euro Courty, NTSC format is for USA, Canada,

if you don’t know which one you need, please feel free to contact us.

1. No Picture after providing power
May be the power supply voltage abnormity, please check the power supply voltage and pole whether exactitude.
Please check all the conecting cable and monitors whether be connected correctly or not.

2. The picture level direction have flowing interference ripples
May be caused by the power supply AC ripples, it need filter the wave of the power supply.
Check the monitor and peripheral equipments used.

3. The picture background color changes continuously
The fluorescent lamp’s electromagnetic field cause color roll. This is proper phenomenon of the cameras.
Reduce the fluorescent lamp numbers or increase the distance between the camera and the fluorescent lamps can
improve it.
Use Power supply external sync. Camera can solve it.

4.The picture smear too mass
The power supply’s voltage unstable
Connecting cables not connect correctly or have high impedance.

waterproof Mini CCTV CAMERA 8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Mini Camera WIITH HD Wide-angle LENS

waterproof Mini CCTV CAMERA 8PCS IR 940nm No red storm Nightvision Sony 700TVL Bullet Mini Camera WIITH HD Wide-angle LENS

Additional information

Power Supply(V)

12

Wall Bracket

Ceiling

name

HD MINI camera

lens

2.8MM

IR Led

8pcs ir led

color

Black

Audio Output

Other

Dimensions (L x W x D)(mm)

3*8.5CM

Lens (mm)

2.8mm

Sensor Brand

SONY

Power Consumption(W)

24

Style

Mini Camera

Brand Name

shrxy

Connectivity

Closed System/CCTV Wired

High Definition

960H(HD)

Special Features

Vandal-proof

is_customized

Yes

type

Mini Outdoor Invisible 8 IR 940nm

Video Compression Format

MJPEG,H.264

Supported Operating Systems

Windows 7,Windows Vista,Windows 98,Mac os,Windows 8,Windows XP

Viewing Angle (Degree)

115

Minimum Illumination(Lux)

0.01

Sensor

CCD

Technology

Infrared

IR Distance(m)

10M
